CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-5
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
<DIODE>
D610 ! 8-719-510-53 DIODE D4SB60L
D612 8-719-911-19 DIODE 1SS119-25
D613 8-719-304-63 DIODE RM11C
D620 8-719-911-19 DIODE 1SS119-25
D631 8-719-063-73 DIODE D1NL20U-TR
D632 8-719-059-23 DIODE P6KE200AG23
D633 8-719-069-63 DIODE ERB38-06V1
D634 8-719-911-19 DIODE 1SS119-25
D635 8-719-110-53 ZENER DIODE RD20ESB2
D637 8-719-911-19 DIODE 1SS119-25
D650 8-719-064-49 DIODE D4SBL40
D651 8-719-063-73 DIODE D1NL20U-TR
D652 8-719-052-91 DIODE D4SBS4-F
D653 8-719-022-97 DIODE D2S4MF
D654 8-719-022-97 DIODE D2S4MF
D655 8-719-063-73 DIODE D1NL20U-TR
D656 8-719-911-19 DIODE 1SS119-25
D660 8-719-110-57 ZENER DIODE RD22ESB2
D661 8-719-110-31 ZENER DIODE RD12ESB2
D663 8-719-911-19 DIODE 1SS119-25
D664 8-719-110-57 ZENER DIODE RD22ESB2
D665 8-719-911-19 DIODE 1SS119-25
D666 8-719-911-19 DIODE 1SS119-25
D680 8-719-989-87 DIODE YG802C09
D681 8-719-109-89 ZENER DIODE RD5.6ESB2
D682 8-719-121-26 ZENER DIODE RD9.1ESL2
D683 8-719-911-19 DIODE 1SS119-25
D690 8-719-911-19 DIODE 1SS119-25
D692 8-719-911-19 DIODE 1SS119-25
<FUSE>
F601 ! 1-576-233-11 FUSE (H.B.C.) (6.3A/250V)
<FERRITE BEAD>
FB630 1-410-396-41 FERRITE 0.45µH
FB632!1-410-397-31 FERRITE 1.1µH
<IC>
IC610 8-749-015-89 IC MZ1530
IC630 8-759-535-32 IC FA13842P
IC650 8-749-012-49 IC DM-57N
IC651 8-759-592-79 IC BA00AST-V5
IC652 8-759-496-15 IC BA05ST-V5
IC653 8-759-450-47 IC BA05T
IC654 8-759-643-66 IC µPC2912HF(12)
IC680 8-759-321-95 IC HA17431PA
<COIL>
L610 1-419-126-21 COIL, CHOKE (AFC) 216µH
L611 1-411-674-11 INDUCTOR 68µH
L650 1-414-742-21 INDUCTOR 22µH
L651 1-414-742-21 INDUCTOR 22µH
L652 1-412-529-11 INDUCTOR 22µH
L653 1-412-529-11 INDUCTOR 22µH
L680 1-414-742-21 INDUCTOR 22µH
<PHOTO COUPLER>
PH620 8-749-924-35 PHOTO COUPLER ON3171-R
PH630 8-749-924-35 PHOTO COUPLER ON3171-R
<IC LINK>
PS650!1-533-593-31 LINK, IC (2A/90V AC, 60V DC)
<TRANSISTOR>
Q603 8-729-045-39 TRANSISTOR MX0842AB-F
Q610 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q621 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q630 8-729-045-03 TRANSISTOR 2SK2647-01MR-F91
Q631 8-729-041-66 TRANSISTOR 2SC4015TV2
Q632 8-729-041-66 TRANSISTOR 2SC4015TV2
Q633 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q650 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q651 8-729-230-45 TRANSISTOR 2SC2458-YGR
Q652 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q653 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q654 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q667 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q670 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q671 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q691 8-729-119-78 TRANSISTOR 2SC2785-HFE
<RESISTOR>
R601 ! 1-220-825-91 CARBON 330K 5% 1/2W
R602 1-216-465-11 METAL OXIDE 27K 5% 2W F
R603 1-247-895-91 CARBON 470K 5% 1/4W
R604 1-216-113-00 RES,CHIP 470K 5% 1/10W
R605 1-216-113-00 RES,CHIP 470K 5% 1/10W
R606 1-216-097-91 RES,CHIP 100K 5% 1/10W
R607 1-216-097-91 RES,CHIP 100K 5% 1/10W
R608 1-216-073-00 RES,CHIP 10K 5% 1/10W
R609 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R610 1-217-152-00 METAL 0.33 10% 2W
R611 1-217-153-00 METAL 0.47 10% 2W
R612 1-249-429-11 CARBON 10K 5% 1/4W
R613 1-216-089-91 RES,CHIP 47K 5% 1/10W
R614 1-247-807-31 CARBON 100 5% 1/4W
R615 1-249-427-11 CARBON 6.8K 5% 1/4W
R616 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R617 1-249-417-11 CARBON 1K 5% 1/4W
R618 1-216-369-00 METAL OXIDE 1 5% 2W F
R620 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R621 1-249-432-11 CARBON 18K 5% 1/4W
G
