CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-6
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
R622 1-216-089-91 RES,CHIP 47K 5% 1/10W
R623 1-218-642-11 METAL OXIDE 100K 5% 1W F
R624 1-218-642-11 METAL OXIDE 100K 5% 1W F
R625 1-216-349-00 METAL OXIDE 1 5% 1W F
R626 1-216-349-00 METAL OXIDE 1 5% 1W F
R627 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R628 1-216-695-11 METAL CHIP 68K 0.5% 1/10W
R629 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R630 1-249-387-11 CARBON 3.3 5% 1/4W F
R632 1-215-399-00 METAL 120 1% 1/4W
R633 1-260-135-11 CARBON 1M 5% 1/2W
R634 1-260-135-11 CARBON 1M 5% 1/2W
R635 1-216-465-11 METAL OXIDE 27K 5% 2W F
R636 1-247-863-91 CARBON 22K 5% 1/4W
R637 1-219-134-11 FUSIBLE 0.1 10% 1/4W
R638 1-219-134-11 FUSIBLE 0.1 10% 1/4W
R649 1-249-437-11 CARBON 47K 5% 1/4W F
R650 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R652 1-216-113-00 RES,CHIP 470K 5% 1/10W
R653 1-249-413-11 CARBON 470 5% 1/4W
R654 1-211-796-11 FUSIBLE 1 5% 1/2W F
R655 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R656 1-260-292-11 CARBON 1 5% 1/2W
R657 1-249-443-11 CARBON 0.47 5% 1/4W F
R658 1-216-073-00 RES,CHIP 10K 5% 1/10W
R659 1-216-049-91 RES,CHIP 1K 5% 1/10W
R660 1-216-073-00 RES,CHIP 10K 5% 1/10W
R661 1-247-807-31 CARBON 100 5% 1/4W
R662 1-216-073-00 RES,CHIP 10K 5% 1/10W
R663 1-216-073-00 RES,CHIP 10K 5% 1/10W
R664 1-216-073-00 RES,CHIP 10K 5% 1/10W
R665 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R666 1-216-073-00 RES,CHIP 10K 5% 1/10W
R667 1-216-089-91 RES,CHIP 47K 5% 1/10W
R668 1-215-457-00 METAL 33K 1% 1/4W
R670 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R671 1-216-677-11 METAL CHIP 12K 0.5% 1/10W
R672 1-216-664-11 METAL CHIP 3.6K 0.5% 1/10W
R673 1-216-073-00 RES,CHIP 10K 5% 1/10W
R674 1-216-097-91 RES,CHIP 100K 5% 1/10W
R675 1-216-668-11 METAL CHIP 5.1K 0.5% 1/10W
R676 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R677 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
R678 1-216-391-11 METAL OXIDE 1.5 5% 3W F
R680 1-215-475-00 METAL 180K 1% 1/4W
R681 1-216-073-00 RES,CHIP 10K 5% 1/10W
R682 1-216-049-91 RES,CHIP 1K 5% 1/10W
R683 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R684 1-216-073-00 RES,CHIP 10K 5% 1/10W
R685 1-216-049-91 RES,CHIP 1K 5% 1/10W
R686 1-216-033-00 RES,CHIP 220 5% 1/10W
R687 1-216-081-00 RES,CHIP 22K 5% 1/10W
R688 1-215-473-00 METAL 150K 1% 1/4W
R693 1-260-085-11 CARBON 68 5% 1/2W
R694 1-216-073-00 RES,CHIP 10K 5% 1/10W
R695 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R696 1-249-407-11 CARBON 150 5% 1/4W
<RELAY>
RY602!1-755-318-11 RELAY, POWER
RY603!1-755-067-21 RELAY
<SPARK GAP>
SG601!1-533-982-11 GAP, SPARK
<TRANSFORMER>
T601 ! 1-429-180-11 TRANSFORMER, LINE FILTER
T620 1-433-894-11 TRANSFORMER, CONVERTER (PIT)
T621 1-429-992-11 TRANSFORMER, CONVERTER (PRT)
T630 1-433-895-31 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR>
TH601 ! 1-809-260-11 THERMISTOR, POWER
THP601! 1-809-827-31 THERMISTOR, POSITIVE
<VARISTOR>
VDR601! 1-801-268-51 VARISTOR TNR14V471K660
VDR602! 1-810-622-11 VARISTOR
***************************************************************************
* A-1346-827-B D BOARD, COMPLETE
[U/C for Japan-made set]
* A-1346-859-B D BOARD, COMPLETE [AEP]
* A-1346-860-B D BOARD, COMPLETE
[U/C for Mexico-made set]
***************************
3-710-578-01 COVER, VOLUME, 6 MOLD (RV901)
4-070-828-01 INSULATING SHEET (Q515)
4-070-829-01 INSULATING SHEET (IC502) [U/C]
4-070-829-02 INSULATING SHEET (IC502) [AEP]
4-070-830-01 INSULATING SHEET (IC701)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC701, Q704, Q705, Q905, Q906, R918)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 TT(B)
(D511, IC502, Q508, Q515, R547)
<CAPACITOR>
C501 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C502 1-136-169-00 FILM 0.22µF 5% 50V
C503 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C504 1-163-017-00 CERAMIC CHIP0.0047µF 10% 50V
C505 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C506 1-137-194-81 FILM 0.47µF 5% 50V
C507 1-136-169-00 FILM 0.22µF 5% 50V
GD
