Sony TRINITRON KV-DA29M81 - Page 92

– 102 –
KV-DA29M81
RM-W105
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
BH1 BOARD VOLTAGE LIST AND WAVEFORM
215 0.3
216 0
217 0
218 0
219 0
220 1.8
221 0
222 0
223 0
224 3.2
225 0
226 0
227 0
228 3.3
229 0
230 0
231 0
232 0
233 0
234 0
235 0
236 1.8
237 0
238 0
239 3.1
240 3.1
IC3302 1 3.3
2 1.6
3 3.3
4 1.5
5 1.5
60
7 (1.2)[1.6]
8 1.3
9 3.3
10 (11.8)[1.3]
11 1.5
12 0
13 1.7
14 0
15 3.3
16 1.7
17 3.0
18 2.8
19 3.2
20 2.7
21 0
22 0.1
23 0.1
24 0
25 0.2
26 0.2
27 0.1
28 0.1
29 3.3
30 0
31 1.5
32 (11.8)[0]
33 0.1
34 0.1
35 3.3
36 1.9
37 1.5
38 0
39 1.3
40 1.3
41 3.3
42 0.8
43 3.3
44 0
45 1.5
46 0
47 1.5
48 1.5
49 3.3
50 1.8
51 1.5
52 0
53 1.3
54 1.3
55 3.3
56 0.8
57 (-0.1)[*]
58 0
59 1.7
60 1.9
61 1.9
62 0.1
63 0.1
64 0.1
65 0
66 0
67 3.3
68 1.4
69 0
70 1.2
71 1.7
72 0
73 0
74 1.5
75 3.3
76 1.5
77 1.6
78 0
79 (1.3)[1.6]
80 0.1
81 3.3
82 1.5
83 1.3
84 0
85 1.8
86 0
IC3303 1 3.3
2 0.1
30
4 (*)[0.1]
5 (3.3)[*]
IC3305 1 3.3
20
3 1.5
4 0.3
5 1.6
6 1.9
70
8 (0)[*]
90
10 0
11 0
12 1.9
13 2.6
14 3.3
IC3306 1 3.3
20.3
30
40.3
5 (3.3)[*]
IC3307 1 4.5
20
3 1.2
4 3.3
5 5.0
IC3310 1 3.3
20
3 1.2
4 2.5
5 3.3
IC3311 1 3.3
20
3 1.2
4 2.5
5 3.3
Q3105 B 3.3
C 4.6
E 3.1
Q3106 B (*)[3.3]
C4.6
E3.2
Q3305 B 2.3
C0
E 1.9
Q3313 B 0.7
C (*)[0]
E (*)[1.3]
Q3314 B 1.3
C2.5
E0.7
Q3320 B 2.4
C (*)[4.9]
E1.6
Q3321 B 2.6
C0
E 3.3
Q3322 B 2.0
C (*)[0]
E 3.3
Q3323 B 2.3
C 4.9
E (*)[1.6]
Q3324 B 2.4
C0
E 3.2
Q3325 B 2.4
C0
E3.2
Ref Pin No. Voltage[v]
Q3901 B 0
C3.2
E (0.3)[*]
Q3902 B 3.2
C1.9
E1.9
H1 BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]
IC1900 I 3.2
G0
O 2.9
H2 BOARD VOLTAGE LIST
