Sony TRINITRON KV-DA29M81 - Page 91

– 101 –
KV-DA29M81
RM-W105
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
BH1 BOARD VOLTAGE LIST AND WAVEFORM
IC3204 1 3.3
20
3 1.5
4 3.3
5 1.6
6 1.7
70
80
90
10 0
11 0
12 0
13 1.6
14 2.4
15 3.3
IC3205 1 3.3
2 3.3
3 1.8
4 1.2
50
IC3301 1 3.3
2 1.6
30
4 1.6
50
60
7 0.3
8 3.3
9 1.6
10 1.8
11 0
12 3.2
13 0
14 0
15 0
16 3.3
17 0
18 1.1
19 2.5
20 2.1
21 1.5
22 1.1
23 2.5
24 0.7
25 2.1
26 2.5
27 0
28 1.6
29 1.5
30 1.5
31 1.1
32 2.5
33 0
34 3.5
35 0
36 3.2
37 0
38 (*)[0]
39 3.3
40 1.5
41 2.5
42 0
43 2.5
44 0
45 3.3
46 0
47 0
48 3.3
49 0
50 2.4
51 0
52 0
53 0
54 0
55 0
56 0
57 1.8
58 0
59 0
60 0
61 0
62 0
63 0
64 0
65 3.3
66 0
67 0
68 0
69 0
70 0
71 0
72 0
73 1.6
74 0
75 0.8
76 0.8
77 0.3
78 3.3
79 0.6
80 0
81 1.9
82 0.6
83 0.5
84 3.3
85 0.6
86 0
87 0
88 (*)[1.8]
89 0
90 1.8
91 0
92 3.3
93 0
94 (-24.5)[0]
95 1.6
96 1.8
97 (*)[1.8]
98 0.6
99 0.6
100 0.6
101 0.6
102 (0)[0.6]
103 (0)[0.6]
104 0
105 (0.4)[0.1]
106 0.5
107 0.4
108 0.5
109 0.5
110 0.5
111 3.3
112 0
113 0.5
114 0.5
115 0.6
116 0.6
117 0.5
118 0.5
119 1.8
120 0
121 0.6
122 0.6
123 0.1
124 0
125 0.8
126 0
127 0.1
128 3.3
129 0.8
130 1.2
131 1.2
132 1.5
133 (1.8)[*]
134 0
135 1.8
136 1.5
137 (0)[1.5]
138 0
139 0.7
140 (0)[1.2]
141 0
142 (3.3)[*]
143 1.2
144 *
145 1.8
146 1.6
147 1.5
148 0
149 1.8
150 1.5
151 1.1
152 0.1
153 0.1
154 0.1
155 (0)[*]
156 3.3
157 0.1
158 0
159 0
160 0.1
161 0
162 0
163 1.8
164 0
165 0
166 0.1
167 0.1
168 (*)[2.7]
169 0
170 1.4
171 3.3
172 1.4
173 3.3
174 3.3
175 0
176 1.8
177 2.8
178 3.1
179 1.7
180 1.7
181 (1.7)[*]
182 0
183 3.3
184 1.5
185 1.3
186 1.4
187 (1.2)[1.6]
188 1.5
189 0
190 1.8
191 1.5
192 1.5
193 1.8
194 1.3
195 1.4
196 0
197 3.3
198 (0.1)[0.4]
199 (1.2)[1.6]
200 1.6
201 1.5
202 1.5
203 1.8
204 0.7
205 0.7
206 0
207 1.8
208 0
209 0
210 0
211 3.3
212 0
213 0
214 0.1
