Sony TRINITRON KV-DA29M81 - Page 90

– 100 –
KV-DA29M81
RM-W105
Ref Pin No. Voltage[v]
IC2007 1 0
2 1.2
3 2.4
4 (1.4)[1.1]
50
60
70
80
90
10 0
11 0
12 0
13 0
14 0
15 0
16 0
17 0
18 0
19 0
20 0
21 0
22 0
23 0
24 3.2
25 0
26 0
27 0
28 0
29 3.2
30 0
31 0
32 0
33 0
34 0
35 0
36 3.2
37 0
38 0
39 0
BC BOARD VOLTAGE LIST
Ref Pin No. Voltage[v] Ref Pin No. Voltage[v]
40 0
41 0
42 0
43 0
44 0
45 0
46 0
47 0
48 0
49 0
50 2.4
51 0
52 0
53 0
54 0
55 0
56 0
57 0
58 0
59 2.4
60 0
61 0
62 0
63 0
64 0
65 0
66 0
67 0
68 0
69 0
70 0
71 0
72 3.2
73 0
74 3.2
75 3.9
76 3.9
77 0
78 1.1
79 0.8
80 1.7
81 1.1
82 0
83 (1.0)[1.4]
84 2.4
85 0.7
86 0.7
87 2.4
88 0
89 0
90 1.7
91 0
92 (1.6)[2.4]
93 0
94 0
95 (0.8)[1.6]
96 (0.8)[1.1]
97 0
98 0
99 0
100 2.4
Q2005 B 2.8
C 8.9
E 2.1
Q2006 B 2.9
C 8.9
E 2.3
Q2009 B 5.6
C 8.9
E 5.0
Q2018 B 3.8
C0
E 4.5
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
IC6200 1 7.9
2 2.1
3 3.9
40
5 2.1
6 1.0
7 7.9
8 11.9
IC6201 1 0.8
2 0.8
3 0.8
4 -15.0
5 1.2
6 1.2
7 8.1
8 11.9
IC6202 1 0
2 3.0
3 4.8
4 4.9
5 -15.0
6 2.4
7 (2.5)[2.6]
8 1.8
90
10 11.9
VM BOARD VOLTAGE LIST
IC1800 1 0.5
2 0.5
3 -14.8
40
5 11.9
Q5400 B 1.5
C 8.4
E 0.9
Q5401 B 1.6
C 5.0
E 1.0
Q5402 B 7.1
C 9.0
E 6.4
Q5403 B 6.4
C 9.0
E (6.0)[6.1]
Q5404 B 5.0
C0
E 5.7
Q5405 B 5.7
C0
E (6.0)[6.1]
Ref Pin No. Voltage[v]
Q5406 B 133.6
C 67.6
E 134.2
Q5407 B 1.3
C 67.6
E (0.7)[0.8]
Q6200 B 0
C 2.1
E0
Q6201 B 0.5
C 11.2
E 0.7
Q6202 B 7.9
C0
E 7.8
Q6203 B 7.9
C 11.8
E 7.8
Q6204 S 0
G 7.8
D 22.5
