KV-21FK120
KV-21FK120
1 RGB POWER ON MUTE AMUT
RGB POWER ON MUTE
00
2 RGB Mute before OSD PMUT
RGB MUTE(EXCEPT OSD)
01
3 Cutoff R L CORL
R CUTOFF lower
212
4 Cutoff R H CORH
R CUTOFF upper
00
5 Cutoff G L COGL
G CUTOFF lower when Color Temp. is
"Cool" and "Neutral"
197
6 Cutoff G H COGH
G CUTOFF upper when Color Temp. is
"Cool" and "Neutral"
00
7 Cutoff B L COBL
B CUTOFF lower when Color Temp. is
"Cool" and "Neutral"
176
8 Cutoff B H COBH
B CUTOFF upper when Color Temp. is
"Cool" and "Neutral"
00
9 ABL SEL ABLS
ABL SELECT
00
10 ACL SPEED ALSP
ACL SPEED
00
11 ACL SPE ALRS
ACL RECOVER SPEED
02
12 ACL ASPE ALAS
ACL ATACK SPEED
09
13 ABL GAIN ABLG
ABL GAIN
05
14 ACLASPE2 ALS2
ACL ATACK SPEED(2)
02
15 AKB MODE AKBM
AKB MODE
00
16 AKB P[5:0] AKBP
AKB PULSE HEIGHT
16
17 OSD LIMIT OSDL
OSD LIMMIT SELECT
00
18 Y/U/V UVINV UVIN
U/V INVERT
00
19 U/V GAIN UVG
UV OFFSET CANCELER ON
00
20 U IN OFFSET UOFS
U IN OFFSET
07
21 V IN OFFSET VOFS
V IN OFFSET
07
22 ANA ACL GAIN AALG
ANALOG ACL GAIN CONTROL
00
23 ANA ACL ON AALS
ANALOG ACL ON/OFF CONTROL
01
24 UV_DITHER_EN UVDE
UVIN DITHER ENABLE
00/01
25 UV_DITHER_TEST UVDT
UVIN DITHER TEST
00/06
RGB
Service
Group
No. Name OSD Description
Initial Data
(DEC)
