Sony TRINITRON RM-Y194 - Page 31

31
KV-21FK120
KV-21FK120
1 AFC FREE RUN HFFR
AFC1 FORCE FREERUN
00
2 HFREE UP HFUP
H FREERUN FREQUENCY UP(700Hz)
00
3VJP WIDTH JSWW
Jump Pulse Width
00
4 V/EW DAC CLK CONTROL EWCL
EW/VRAMP DA CLOCK SELECT
00/00
5 FREE RUN OFFSET XF0A
VCXO FREERUN ADJUST
00
6 BG START BGST
BGP(for PLL) TIMING
16/01
7 VCXO CTL XPHA
VCXO PHASE ADJUST
10
8 Ramp Slew Rate HRMP
AFC2 TIME CONSTANT
03
9 Ref Charge pump RPLU
REF PLL TIME CONSTANT
03
10 Ref VCO RPLB
REF PLL TIME CONSTANT
01
11 VCXO FREE RUN XF0B
VCXO Fo ADJUST
00
12 REF FB SW RPLS
REF VCO FB LOOP SELECT
00
13 Sync Sepa Mas
k
SSM
SyncSepaMasking CONTROL
00
14 V-sag VSAG
V-SAG prevent ON
00
15 AFC2 Gain AFC2
AFC2 GAIN CONTROL
03
16 V RAMP FIL OFF VRFL
V RAMP FILTER SWITCHING OFF for 16:9 mode
& YUV input
01
17 LPY SYNC SSLP
LPF pre SYNC SEPA ON/OFF
01
18 B PLL Change pump XPLU
ACP TIME CONSTANT
01
19 8FSC SEL 8FSC
8fscCLK Skew OFF
01/00
20 4FSC SEL2 4FS2
4fscCLK Skew OFF
01/00
21 V_CD_MODE2 CDM2
V_LOGIC SW
01
22 Add. FTN BGP C BGPC
BGP C
00
23 Add. FTN BGP SEL MHDL
BGP SEL
01
24 V FREE BFRE
force V FREERUN
00
25 AFC2 RAMP POS HRPP
FRAMP RRAMP H OUT CONTROL RANGE
08
26 CLOCK SEL DSC
K
DS DAC CLK SW for 16:9 & YUV/Composite
01/00
27 VBLK HALFKIL VBH
K
V BLK HALF KILL
00
28 V PLS WIDTH VPW
V Pulse Wide
01
29 D THRESHOLD LEVEL DTH
DITHER THRESHOLD LEVEL CONTROL
at IIC AUTOD=ON
00
30 LPF SYNC ON SLON
LPF SYNC ON
01
31 SYNC SLICE LVL(V)_W VSSW
SYNC SLICE LEVEL(V) Wide Window
00
32 AFC2_SEL AF2S
AFC2 timing SW
00
33 V_SYNC_LPF_2 VSL2
Digital V_SYNC_LPF(fall)
00
34 V_SYNC_LPF_1 VSL1
Digital V_SYNC_LPF(rise)
01
35 YUV VSIZE OFFSET VYUV
YUV V-SIZE OFFSET
08
36 YUV VPOS OFFSET VYVP
YUV V-POSITION OFFSET
08
37 YUV HSIZE OFFSET VYHS
YUV H-SIZE OFFSET
08
38 YUV HPOS OFFSET VYHP
YUV H-POSITION OFFSET
07
39 V-SHRINK MODE VSHE
V-SHRINK MODE for AV
00
40 YUV RBL
K
VYRB
YUV RBLK OFFSET
07
41 YUV LBL
K
VYLB
YUV LBLK OFFSET
07
DEFD
Service
Group
No. Name OSD Description
Initial Data
(DEC)
