KV-21FK120
KV-21FK120
1 pedestal CLAMP ON/OFF PCLP
SYNC TIP/PEDESTAL CLAMP SELECT
00
2 VRT Voltage VRT
ADC REFERENCE
(00:1.15Vpp 01:1.25Vpp 10:1.35Vpp 11:1.45Vpp)
01
3 INV 14H CL
K
14HI
4fsc(Skew)CLK POLARITY
00/00
4 14H CLK DLY 14HD
4fscCLK(Skew)CLK DELAY ADJUST
00/00
5 INV DS CL
K
DSI
8fscCLK POLARITY
00/00
6 DS CLK DLY DSD
8fscCLK DELAY ADJUST
00/00
7 AD CLK DLY ADCD
ADC CLK DELAY ADJUST
00/01
8 4FSC SW 4FSC
AD/LOGIC CLK SWAP
00
9 WEAK_SIG_VTH WSTH
WEAK_SIGNAL VTH
00
10 WEAK SIG VIDEO ATT WSVA
WEAK SIGNAL VIDEO ATT
00/00
11 WEAK SIG CHROMA ATT WSCA
WEAK SIGNAL CHROMA ATT
00/00
12 VREF_SEL VREF
AD REFERNCE SELECT(VZ)
00
1HT HT
HALF TONE LEVEL
00
2OSD LVL R OSLR
R OSD LEVEL
25
3OSD LVL G OSLG
G OSD LEVEL
25
4 OSD COMP OSDC
OSD COMP
00
5 OSD LVL B OSLB
B OSD LEVEL
25
1 H/W AKB R INI DATA L HRIL
H/W AKB RED OUTPUT Lower
00
2 H/W AKB R INI DATA H HRIH
H/W AKB RED OUTPUT Upper
01
3 H/W AKB G INI DATA L HGIL
H/W AKB GREEN OUTPUT Lower
00
4 H/W AKB G INI DATA H HGIH
H/W AKB GREEN OUTPUT Upper
01
5 H/W AKB B INI DATA L HBIL
H/W AKB BLUE OUTPUT Lower
00
6 H/W AKB B INI DATA H HBIH
H/W AKB BLUE OUTPUT Upper
01
7 AKB_LIM1<7:0> HLM1
H/W AKB LIM1
06
8 AKB_LIM2<7:0> HLM2
H/W AKB LIM2
12
9 AKA_LIM3<7:0> HLM3
H/W AKB LIM3
21
10 AKB_ADD1<7:0> HAD1
H/W AKB SPEED1
02
11 AKB_ADD2<7:0> HAD2
H/W AKB SPEED2
06
12 AKB_EN HAKE
H/W AKB MANUAL (MCU)/HARD
01
13
AKB_SPEED HASP H/W AKB SPEED
03
14
AKB_SWERR<7:0> HERL H/W AKB ERROR DET THRESH
40
15 AKB_ERRC<7:0> HLMC
H/W AKB ERROR DET TIME
20
16
AKBSWPON<7:0> HPWL
H/W AKB POWER ON TRESH
04
17
AKB_PWERRC HPWC
H/W AKB POWER ON TIME
90
18 H/W AKB2 HOLD TIMER HFMT
POWER ON H/W AKB2 HOLD TIMER(@100msec)
[
0 : No Hold
]
20
19 AKB POW ON MUTE EXIT SPMT
AKB POWER ON MUTE EXIT TIMER(@100msec)
120
OTHERH/W AKB OSD
Service
Group
Service
Group
Name OSD Description
OSD Description
Initial Data
(DEC)
Service
Group
No. Name OSD Description
Initial Data
(DEC)
No.
Initial Data
(DEC)
No. Name
