AUDIO IN connectors
Multi port
(or use multi
output station)
VIDEO IN connector
USB/AV cable for multi-use terminal
(supplied with camera or sold separately)
Connecting a camera with multi port:
Connecting a video device:
AUDIO IN connectors
To AUDIO/VIDEO OUT
connectors
VIDEO IN connector
Audio/video cable (not supplied)
