Specifications
INPUT OUTPUT
(Computer/video)
INPUT A RGB/YPBPR input terminal: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: TTL level high
impedance, positive/negative
Audio input terminal (VPL-EW348/EW345/EW315/
EX345/EX315 only): Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kohms
INPUT B RGB input terminal: Mini D-sub 15-pin female, RGB:
0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal: TTL
level high impedance, positive/negative
Audio input terminal (VPL-EW348/EW345/EW315/
EX345/EX315 only): Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kohms
INPUT C/
INPUT D
HDMI input terminal (Audio output is available only
on VPL-EW348/EW345/EW315/EX345/EX315.):
HDMI 19-pin, HDCP, HDMI audio support
S VIDEO
(SVIDEO IN)
S video input terminal: Mini DIN 4-pin, Y: 1 Vp-p
± 2dB, sync negative, 75 ohms terminated, C: (burst
signal) 0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB,
75 ohms terminated
Audio input terminal (VPL-EW348/EW345/EW315/
EX345/EX315 only): Phono jack × 2, rated input 500
mVrms, input impedance more than 47 kohms
VIDEO (VIDEO
IN)
Video input terminal: Pin jack, 1 Vp-p ± 2 dB, sync
negative, 75 ohms terminated
Audio input terminal (VPL-EW348/EW345/EW315/
EX345/EX315 only): Shared with S VIDEO
OUTPUT MONITOR output terminal: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output terminal (VPL-EW348/EW345/EW315/
EX345/EX315 only): Stereo mini jack, 1 Vrms
(maximum volume, when inputting 500 mVrms), output
impedance 5 kohms
Other terminals RS-232C terminal: D-Sub 9-pin male
HDBaseT
*4
/LAN terminal: RJ45, HDBaseT/
100BASE-TX
HDBaseT transmittable signal: HDMI (Video, Audio),
RS-232C, Ethernet
HDBaseT LAN cable: STP type (CAT5e or higher,
straight, not supplied), Maximum length: 100 m
USB terminal: Type A
USB terminal: Type B
Microphone input (VPL-EW348/EW345/EW315/
EX345/EX315 only): Mini jack
Items Descriptions
Model VPL-EW348/EW345/EW315/EX345/EX340/EX315/EX310
