58
Specifications
Color system NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N
INPUT OUTPUT
(Computer/video)
INPUT A RGB/YPBPR input connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: TTL level high
impedance, positive/negative
Audio input connector (VPL-EW275/EW245/
EW225/EX275/EX245/EX225 only): Stereo mini
jack, rated input 500 mVrms, input impedance more
than 47 kohms
INPUT B RGB input connector: Mini D-sub 15-pin female,
RGB: 0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync
signal: TTL level high impedance, positive/negative
Audio input connector (VPL-EW275/EW245/
EW225/EX275/EX245/EX225 only): Stereo mini
jack, rated input 500 mVrms, input impedance more
than 47 kohms
INPUT C HDMI input connector (Audio output is available
only on VPL-EW275/EW245/EW225/EX275/
EX245/EX225.): HDMI 19-pin, HDCP, HDMI audio
support
S VIDEO
(SVIDEO IN)
S video input connector: Mini DIN 4-pin, Y: 1 Vp-p
± 2dB, sync negative, 75 ohms terminated, C: (burst
signal) 0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB,
75 ohms terminated
Audio input connector (VPL-EW275/EW245/
EW225/EX275/EX245/EX225 only): Phono jack × 2,
rated input 500 mVrms, input impedance more than 47
kohms
VIDEO (VIDEO
IN)
Video input connector: Pin jack, 1 Vp-p ± 2 dB, sync
negative, 75 ohms terminated
Audio input connector (VPL-EW275/EW245/
EW225/EX275/EX245/EX225 only): Shared with S
VIDEO
OUTPUT MONITOR output connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output connector (VPL-EW275/EW245/
EW225/EX275/EX245/EX225 only): Stereo mini
jack, 1 Vrms (maximum volume, when inputting 500
mVrms), output impedance 5 kohms
Other connectors RS-232C connector: D-Sub 9-pin male
LAN connector: RJ45, 10BASE-T/100BASE-TX
USB connector: Type A
USB connector: Type B
Microphone input (VPL-EW275/EW245/EW225/
EX275/EX245/EX225 only): Mini jack
Items Descriptions
Model VPL-EW275/EW245/EW225/EX281/EX275/EX271/
EX245/EX241/EX225/EX221
