Sony WM-FS421 User Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
21
WM-FS421
MAIN HEADPHONE
R707 1-216-845-11 METAL CHIP 100K 5% 1/16W
R708 1-216-849-11 METAL CHIP 220K 5% 1/16W
R709 1-216-809-11 METAL CHIP 100 5% 1/16W
R710 1-216-833-11 METAL CHIP 10K 5% 1/16W
R711 1-216-833-11 METAL CHIP 10K 5% 1/16W
R712 1-216-833-11 METAL CHIP 10K 5% 1/16W
R713 1-216-833-11 METAL CHIP 10K 5% 1/16W
R714 1-216-833-11 METAL CHIP 10K 5% 1/16W
R715 1-216-833-11 METAL CHIP 10K 5% 1/16W
R716 1-216-833-11 METAL CHIP 10K 5% 1/16W
R717 1-216-857-11 METAL CHIP 1M 5% 1/16W
R718 1-216-833-11 METAL CHIP 10K 5% 1/16W
R720 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R721 1-216-833-11 METAL CHIP 10K 5% 1/16W
R722 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VARIABLE RESISTOR >
RV1 1-223-258-11 RES, CARBON ADJ VAR 4.7K
RV2 1-223-278-11 RES, CARBON ADJ VAR 100K
RV301 1-225-184-11 RES, VAR, CARBON 10K/10K(wVOLUME)
RV601 1-241-916-11 RES, ADJ, CARBON 4.7K(TAPE SPEED)
< SWITCH >
S301 1-771-040-21 SWITCH, PUSH(TAPE POWER)
S302 1-771-040-21 SWITCH, PUSH(Y)
S701 1-771-586-41 SWITCH, SLIDE(HOLD OFF-ON)
< THERMISTOR >
TH601 1-803-751-21 THERMISTOR, POSITIVE
< VIBRATOR >
X701 1-579-615-11 VIBRATOR, CRYSTAL(75kHz)
**************************************************************
* 1-681-169-11 HEADPHONE BOARD
*****************
* 1-757-684-11 WIRE (H/P MAIN PWB)
< FERRITE BEAD >
FB102 1-500-245-11 FERRITE 0uH
FB202 1-500-245-11 FERRITE 0uH
< JACK >
J301 1-778-224-11 JACK (SMALL TYPE) (WATERPROOF)(i)
**************************************************************
MISCELLANEOUS
**************
HP701 1-500-648-11 HEAD, MAGNETIC (PLAYBACK)
M601 1-763-683-11 MOTOR, DC(REEL/CAPSTAN)(WITH PULLEY)
ACCESSORIES & PACKING MATERIALS
********************************
3-221-757-11 CLIP, BELT
3-229-657-22 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,PORTUGUESE)
8-953-284-91 HEADPHONE MDR-W014LP
