6
WM-FS421
3-4. BELT
3-5. HEAD, MAGNETIC (HP701)
Reel/Capstan motor
Capstan wheel assy(SP)
Capstan wheel assy(SP)
Belt threading
Belt
Belt
1
Two screws (M1.4)
2
Head, magnetic (HP701)
