WM-FS421
3-2. CHASSIS SUB ASSY
3-3. MAIN BOARD AND MECHANISM DECK
MAIN board
1
Two claw
s
Chassis sub assy
2
3
Screw (M1.4 ) Toothed Lock
1
Remove the solder (four points
)
5
Stopper (L2)
4
MAIN board
2
Remove the solder
6
Mechanism deck
