Figure6.11PARTLISTOFIDLERASSEMBLY(8034011-0090-1)
8
11
6
3
5
2
6
10
4
7
1
9
ITEM
PART#QTYDESCRIPTION
1
7S6485-00002-000
2
M16X1.5BRASSOILSIGHTPLUGWITHREFLECTOR
28034007-0050-12
HARDENEDWASHER
38034011-0030-11
SP-716IDLERAXLESHAFTASS'Y
48034011-0050-12
HUBCAP
5
8034011-0120-12
SP-716IDLERWHEELANDHUBASS'Y
6
B32011-XQ-SKF
4
TAPEREDROLLERBEARING55X90X23
7
S1131-06015-0D7
12
HEX.BOLTCL8.8ZnNiM6-1.0X15(DIN933)
8
S4214-M0550-000
2
KM-11LOCKNUTM55X2
9
S4531-M0550-000
2
MB11LOCKWASHERDIA.55MM
10
S6701-00043-000
2
O-RINGHNBRN12062-240
11
S6732-23001-000
2
HDDFC6VITONMECHANICALSEAL*
INSTALLATION,OPERATIONANDMAINTENANCEGUIDE
32
