The simplest possible configuration is a single tunable antenna according to the
following diagram
:
The link is configurable for any position (ANT 1,2,3,4) you want use.
To select a tunable antenna, refer to the “TUN ANT” item on the main menu.
After selection, on the display, next to the number of the antenna in use will
appear a “t”. In this case the ATU will be bypassed.
Set "Kenwood" in the control box as the communication protocol used, the
speed of the communication is “owner settable.”
For the connection cable, refer to chapter 13.5.
.
