17. CHARACTERISTICS / SPECIFICATIONS
- The smallest in its class:
Built-in Power supply and Automatic Antenna Tuner.
Dimension: L 28, H 12, P 38 cm ( 11.02” W, 4.72” H, 14.96” D ) connector
included. Approx. weight about 9,5 Kg (20.9 lbs).
- The most technologically advanced in the world:
Two powerful CPUs are used.
Over 30,000 lines of software, for performance that cannot be found together in
any other amplifier.
- Fully Automatic:
Easy connection with all models "ICOM, YAESU, KENWOOD, TEN-TEC,
FLEX-RADIO, ELECRAFT" for immediate management of the bands, tuner and
antennas.
Same performance with all makes and some homemade rigs.
The operator has to only move the “Frequency Tuning Knob” of the transceiver.
- Wide frequency coverage:
1.8 MHz to 50 MHz including WARCs.
60 m band, where permitted.
- Fully solid state:
Solid 1.5 KW out; 50 MHz included (+/- 0.5 dB).
Switchable in MAX (full power), MID (1KW) or LOW (500 W), power selected
according to the operator’s requirement or automatic for amplifier protection.
No warmup time, immediately ready!
Virtually limitless life of the amplification device.
Only one LD / MOSFET used rated of 1.8 KW out.
- Automatic Antenna Tuner built-in:
Capable of matching up to 5:1 SWR on HF, and 2.5:1 SWR on 6 meters.
Capable of program controlling 4 aerials (SO239 connectors).
Program up to 2 aerials for each band.
Management of SteppIR / Ultrabeam aerials (tunable).
Also measures the SWR of the antenna and cable system.
Bands, aerials, Tuning conditions are changed in 10 msec.
Bands, aerials and Tuning conditions are managed so that in “STBY“, only the
exciter is passed through to the output.
Max. attenuation 0.8 dB.
ATU bypass capable.
- SO2R.
- Two inputs available:
SO239 connectors.
- High power gain (up to 15 dB):
In “OPERATE“ the required drive power is automatically set with the ALC
connection.
In “STANDBY“ the exciter is automatically reset to full power.
