5.7. SWAT
Depending on the model, your Diverge STR comes with either one or two SWAT bags that can
be stored in the down tube.
4
FIG. 4
 Open the SWAT door to insert the SWAT bags.
 Slide the bag into the lower portion of the down tube.
 If your model comes with a second bag, insert the smaller bag first in the upper portion of
the down tube followed by the larger bag in the lower portion of the down tube.
A
B
B
C
D
5
FIG. 5
 There are accessory mounts on the top tube intended for bags (A). Water bottle cages can
be mounted to the bottom of the down tube and on the SWAT compartment door (B), the
seat tube (C), and the fork (D). Clearance will vary with frame size.
Apply grease to all accessory mount bolts before installing.
Make sure not to fasten bag straps around the Future Shock.
CAUTION: Only use SWAT bolts that come pre-installed on your Diverge STR.
Aftermarket bolts may be too long and could damage the frame.
