22
FRAME & FRAMEPOST COMPATIBILITY
FRAME 49 cm 52 cm 54 cm 56 cm 58 cm 61 cm
FP1
INCLUDED INCLUDED COMPAT. COMPAT. COMPAT.
FP2
COMPAT. COMPAT. INCLUDED COMPAT. COMPAT.
FP3
COMPAT. COMPAT. COMPAT. INCLUDED COMPAT.
FP4
INCLUDED INCLUDED COMPAT. COMPAT. INCLUDED
FP5
COMPAT. COMPAT. INCLUDED COMPAT. COMPAT.
FP6
COMPAT. COMPAT. COMPAT. INCLUDED COMPAT.
FP7
COMPAT. COMPAT. COMPAT. COMPAT. INCLUDED
FP8
INCLUDED
FP9
INCLUDED
50
110
55
121
60
65
70
75
80
85 90 95 100 105 110 115 120 125
132
143 154 165
176
187
198
209
220
232
243
254
265 275
FP1
30
38
FP235
43
FP340
48
FP445
53
FP550
58
FP655
65
FP760
72
FP828
34
FP940
48
kg
lb
7.2. FRAMEPOST ASSEMBLY
WARNING! Do not ride your Diverge STR without all components of the STR
system properly installed and connected as outlined in this manual, including
the damper and damper tendon as well as the framepost boot and boot bolt.
Failure to do so could result in structural damage to the framepost and could
cause you to lose control and fall.
1
FIG. 1
Insert the damper into the top tube.
Thread in the damper bolts until they are finger tight.
Damper bolts are torqued after the tendon is installed (FIG. 7).
WARNING! Size 49 frames have an additional travel-reducing spacer
(highlighted in blue) attached to the shaft of the damper. Do not remove this
spacer. Removal of the spacer can damage the framepost and cause you to
lose control and fall.
Weight ranges
for FP1-FP7
(52 cm-61 cm
frames)
Weight ranges
for FP8 &
FP9 for
(49 cm frame)
Rider weight
