23
A
B
C
D
2
FIG. 2
 Place the damper cover (A) over the damper. Using a torque wrench and a 2 mm hex bit,
torque the damper cover bolts (B) to 0.8 Nm / 7 in-lbf or until they’re finger tight.
 Insert the compression adjustment lever (C). Using a torque wrench and a 2 mm hex bit,
torque the compression adjustment lever bolt (D) to 0.8 Nm / 7 in-lbf or until it’s finger
tight.
Do not to push the damper shaft too far into the damper before you put the
cover on or it will be difficult to pull it back out.
3
FIG. 3
 Push the damper shaft into the damper to make room for the framepost boot and tendon.
