Specialized DIVERGE STR - Page 8

6
FRAME SIZE 49 52 54 56 58 61
A STACK (mm)
569 576 593 609 633 659
B REACH (mm)
365 374 383 392 401 410
C HEAD TUBE LENGTH (mm)
100 100 115 130 155 182
D HEAD TUBE ANGLE (°)
70 70.5 71.25 71.75 71.75 71.75
E BOTTOM BRACKET HEIGHT (mm)
270 265 265 265 265 265
F BOTTOM BRACKET DROP (mm)
80 85 85 85 85 85
G TRAIL (mm)
69 66 61 57 57 57
H FORK LENGTH (FULL) (mm)
390 390 390 390 390 390
I FORK RAKE/OFFSET (mm)
55 55 55 55 55 55
J FRONT CENTER (mm)
607 612 619 629 645 663
K CHAINSTAY LENGTH (mm)
429 429 429 429 429 429
L WHEELBASE (mm)
1023 1027 1034 1044 1060 1078
M TOP TUBE LENGTH (mm)
527 540 556 570 586 602
N STANDOVER HEIGHT
704 730 753 778 804 833
O SEAT TUBE LENGTH (mm)
390 430 470 500 530 560
P SEAT TUBE ANGLE (°)
74.5 74.25 74 74 74 74
