Grade Entry
SelecttheGradeEntryiconandpressandreleasebutton4toopentheGradeEntrymenu.
Buttons6/7canbeusedtotogglebetweenStepandGoandDigitSelect.
Press and release button 4 to confirm the selection.
Step and Go Digit Select
Grade Display
SelecttheGradeDisplayiconandpressandreleasebutton4toopentheGradeDisplaymenu.
ThedesiredGradeDisplayMode(Percent/Permille/Degree)canbeselectedusingthebuttons6/7.
Press and release button 4 to confirm the selected display mode.
Sensitivity Selection
Select the Sensitivity icon and press and release button 4 to open the Sensitivity menu. The
desiredSensitivity:Low,Mid(Default)andHigh)canbeselectedusingthebuttons6/7. Press
and release button 4 to confirm the selected Sensitivity.
HI-alert Selection
SelecttheHIiconandpressandreleasebutton 4toopentheHI-alertmenu.ThedesiredHI-alert:
5min.(Default),30secondsandHI-Off)canbeselectedusingthebuttons 6/7. Press and release
button 4toconfirmtheselectedHI-alert.
