HOW TO USE THE LASER SYSTEM
POWERING THE LASER
Batteries
WARNING
Ni-MHbatteriesmaycontainsmallamountsofharmfulsubstances.Besuretochargethebattery
beforeusingitforthefirsttime,andafternotusingitforanextendedlengthoftime.Chargeonlywith
specifiedchargersaccordingtodevicemanufacturer‘sinstructions.Donotopenthebattery,dispose
ofinfireorshortcircuit;itmayignite,explode,leakorgethotcausingpersonalinjury.Disposein
accordance with all applicable federal, state, and local regulations. Keep the battery away from
children.Ifswallowed,donotinducevomiting.Seekmedicalattentionimmediately
Recharging the Batteries
ThelaserisshippedwitharechargeableNi-MHbatterypack.
Note: TheapproximatechargeofthebatteriesisshownatthelefttopsideoftheLCD.
Thechargerrequiresapprox.10hourstochargeemptyrechargeablebatteries.
Forcharging,connecttheplugofthechargertotherechargejackofthebatterypack.
Neworlong-timeout-of-userechargeablebatteriesreachtheirbestperformanceafter
beingchargedandrechargedfivetimes.ForIndoorapplicationsthechargercanbe
usedasapowersupplyfortheGL.
Alkalinebatteriescanbeusedasabackup.Insert4D-cellbatteriesnotingtheplus
(+) and minus (-) diagrams inside the battery housing.
The batteries should only be charged when the laser is between 50° F and 104° F (10°C to
40°C). Charging at a higher temperature may damage the batteries. Charging at a lower
temperature may increase the charge time and decrease the charge capacity, resulting in
loss of performance and shortened life expectancy.
RC602 Radio Remote Control
Powering the RC602
1. Open the battery door using a coin or similar pry device to release the
batterydoortabontheRC602.RC602willbeshippedwithalkaline
batteries Rechargeable batteries can be used optional but need to
bechargedexternally
2.InserttwoAAbatteriesnotingtheplus(+)andminus(-)diagrams
inside the battery housing.
3.Closethe battery door.Pushdown untilit “clicks” intothe locked
position.
Turning On/Off the Radio Remote Control
The radio remote control is a hand-held device that allows you to send operational commands to the laser
from a remote location.
Pressthepowerbuttontoturnontheradioremotecontrol.A“ ”andadditionalverticalbarsappearinthe
right corner of the remote’s top display line indicating the radio connection status between the laser and the
remote control.
Note
:Whentheremotecontrolisinitiallyturnedon,thestandarddisplay(modelnumberandsoftwareversion)
appearforthefirst3seconds,thentheaxessymbolsandlast-enteredgradeforeachaxisbrieflyappearin
theLCD.
Witheverybuttonpress,theLCDbacklightisactivatedandturnsoffautomaticallyifnobuttonispressedfor
8seconds.
To turn off the radio remote control, press and release the power button.
Note
:5minutesafterthelastbuttonpress,theremotecontrolturnsoffautomatically.
