Spektrum DX6I - Pitch Curve; To Access the Pitch Curve Function

121 41&,536.%9Jt3"%*0130(3"..*/((6*%&
1*5$)$637&
Adjustment of the pitch curve is very similar to the throttle curve adjustment described in the preceding section. A
thorough understanding of the throttle curve section will make pitch curve adjustment easier to understand.
The DX6i offers three (3) independent pitch curves: Normal, Stunt 1, Hold. Each pitch curve contains five (5)
adjustable points — L, 1, 2, 3 and H.
50"$$&445)&1*5$)$637&'6/$5*0/
With the transmitter already powered on and the main screen displayed, press and release the ROLLER to
enter the ADJUST LIST.
Reduce photo to 13.5%
ADJUST LIST
MODEL SELECT
Main
Rotate the ROLLER to the right until PITC CUR is highlighted on screen.
Reduce photo to 13.5%
ADJUST LIST
7
THRO CUR
PITC CUR
SWASH MIX
Main
