EXTRACTABLE STRETCHER SUPPORT
For this type of stretcher support, it is not necessary to remove front and rear bumpers to fix the stretcher support inside the vehicle. Simply
place the stretcher support in the desired position considering bulk dimensions described above.
The following picture shows the drilling quotes needed to check the installation surface.
It is imperative to verify that the installation surface is free from pipes, electrical wirings or other elements that could be damaged during
drilling.
Once the device is properly placed, it is possible to mark the position of the fixation points, drill the holes, then fix the device using
appropriate backplates as previously described.
SIDEWAYS MOVABLE STRETCHER SUPPORT AND SIDEWAYS+EXTRACTABLE STRETCHER SUPPORT
Also for this type of stretcher support, it is not necessary to remove front and rear bumpers to fix the stretcher support inside the vehicle.
Simply place the stretcher support in the desired position considering bulk dimensions described above.
Verify that the stretcher support can be moved in the provided directions, free from obstacles and that there is enough space needed for
rescuers.
The following picture shows the drilling quotes needed to check the installation surface.
It is imperative to verify that the installation surface is free from pipes, electrical wirings or other elements that could be damaged during
drilling.
