SPI VALVES SP160 Series User Manual

45
PARTS LIST  SHUT OFF AND DIVERT VALVES
SP161 LONG STROKE SHUT OFF VALVE
LONG STROKE SHUT OFF VALVES
ITEM PART NUMBER DESCRIPTION KIT
1
SP110
SP120
SP130
Actuator (N.O.)
Actuator (N.C.)
Actuator (A/A)
2 SP160-7-1.5-9 Spring Clip ○
3 SP13Z-2.5 Bonnet Clamp
4
SP161-4
SP161-4-DLS
Spool Piece
3” Valve Spool Piece
5 SP161-7-Size-3 Bonnet
6
SP40B-2.5
SP40B-3
SP40B-3.5
SP40B-4
Gasket for 1.5” Valve
Gasket for 2” Valve
Gasket for 2.5” Valve
Gasket for 3” Valve
○
7 SP10-6 Stem O-Ring ○
8
8RS
SP161-7-Size-2E
SP161-7-Size-2V
SP161-7RS-Size-2TS
Shut-o Stem (EPDM)
Shut-o Stem (Viton)
Shut-o Stem (PTFE)
9
SP13HC-2.5
SP13HC-3
SP13HC-3.5
SP13HC-4
Clamp for 1.5” Valve
Clamp for 2” Valve
Clamp for 2.5” Valve
Clamp for 3” Valve
10 SP160-7-Size-1 Tee Body
11 SP160-9-Size-1 Cross Body
12 SP160-7RS-Size-2TH Seat (PTFE)
○ INCLUDED IN SP120-RBK-SIZE VALVE SERVICE KIT
