19
MICRO / PROXIMITY ACTUATORS
SP120MS MICRO-SWITCH
SP10MS/SP20MS/SP30MS/SP110MS/SP120MS/SP130MS
MICRO-SWITCH
ITEM PART NUMBER DESCRIPTION
1 SP10MS-3B Micro Switches (x2)
2 SP10MS-CG
1/2” NPT Nylon Cable Grip
for 1/4-3/8” OD range
SP10PRX/SP20PRX/SP30PRX/
SP110PRX/SP120PRX/SP 130PRX
PROXIMITY SWITCH
ITEM PART NUMBER DESCRIPTION
1 SP20-DPS
Proximity Switches
(Dual Prewired)
A = Bottom, B = Top
2 SP20PS-PD
Proximity Switch Indicator
(Stainless Steel Prox Dog)
with Set Screw
3 SP20-4P-NPT
1/2” NPT Adapter to Female
4-Pin M12
** SP20-FWC-CONN
Male M12 to Cable Adapter
(Included but Optional)
Stainless Products’ micro/proximity switch oerings provide a solution for those needing open and closed
feedback on the SP160 family of shuto valves. A simple dual microswitch solution provides two roller-style
microswitches, brackets, hardware, and a cable grip. A contactless dual proximity switch solution provides
two proximity switches that are pre-wired. It also comes with accessories needed to use a four-pin M12
connector. An M12 patch cable or four-conductor cable can be used. Valve feedback provides true open
and closed feedback from the valve iteself via 24VDC signal to your control system.
SP20PRX PROXIMITY SWITCH
ELECTRICAL CONNECTIONS MADE BY USER/CUSTOMER
** ITEM NOT SHOWN
A
B
CABLE GRIP FOR
1/4-3/8” OD
FEMALE
4-PIN M12
To Next Page
