SPI VALVES SP160 Series User Manual

73
PARTS LIST  MODULATING ACTUATOR
SP160 - TAYLOR ACTUATOR ADAPTERS
TAYLOR ADAPTER SPARE PARTS
ITEM PART NUMBER DESCRIPTION KIT
1
LT-160-7-2D
ST-160-7-2D
Large Taylor Stem
Small Taylor Stem
2 SP160-7-1.5-9 Spring Clip ○
3 13H-2 1/16-FJ Taylor Nut (Small Only)
4
SP160-7-1.5-2 3/4
SP160-7-1.5-2 1/16
Large Taylor Adapter
Small Taylor Adapter
5 SP13Z-2.5 Bonnet Clamp
6 SP160-7-Size-3 Bonnet
7
SP13HC-2.5
SP13HC-3
SP13HC-3.5
SP13HC-4
Clamp for 1.5” Valve
Clamp for 2” Valve
Clamp for 2.5” Valve
Clamp for 4” Valve
8
SP40B-2.5
SP40B-3
SP40B-3.5
SP40B-4
Gasket for 1.5” Valve
Gasket for 2” Valve
Gasket for 2.5” Valve
Gasket for 3” Valve
○
9 SP10-6 Stem O-Ring ○
10
SP160-7M-Size-2 Plug and Stem Multi-Taper
SP160-7MT-Size 2
Plug and Stem Straight-Taper
11 SP160-7MT-Size-1 Tee Body
○ INCLUDED IN SP20-RBK-SIZE VALVE SERVICE KIT
