IM-P402-93 AB Issue 7
13
6.5 Wiring - on/off control (All relays shown in the power off position)
Note: It is essential to select the correct sensitivity on the PA20 preamplifier,
(see Installation and Maintenance Instructions for details).
Note:
Terminals
1, 3, 5 and 7
are common
20
19
18
17
16
9
8
7
Input
Level input
+
Capacitance probe
Fig. 12
Control
relay
Select
voltage
internally
N
N
L
L
Pump contactor
Fuse 3 A max.
3 A max.
