IM-P343-37 CTLS Issue 4
3
SP400 Electropneumatic Smart Positioner
2. Safety information
5
2.1 General requirements
2.2 Electrical safety requirements
2.3 Electromagnetic compatibility
3. Technical information
6
3.1 Description
3.2 Technical data
8
3.3 Materials
3.4 Programmable functions 9
4. Options
10
4.1 Pressure gauge block
5. Installation
5.1 Mounting the SP400 positioner - General informaton 19
5.2 Sequence for mounting an SP400 positioner to a linear actuator 20
5.3 Sequence for mounting an SP400 positioner to a rotary actuator 24
5.4 Air supply and connections 28
6. Electrical connections
29
6.1 Guidance notes
6.2 Wiring diagrams
7. Quick start procedure
33
7.1 2-port valves
7. 2 3-port valves
1. Contents
Index continued on page 4
