SP400 Electropneumatic Smart Positioner
12.1 Main menu display functions
Display Description
SET UP
NOW
Indicates that the SP400 positioner fitted to the valve has not been programmed or
commissioned.
SP400
MENU
Indicates that you have now entered the SP400 main menu.
Provides access to:
•
View the version of the embedded software.
•
Retain temporary changes to menu values (RETRN).
•
Recall previously stored menu values (RTAIN).
•
Reset to default values (RESET).
MAN OP
Provides access to manual control (MCTL) and current calibration (C-CAL).
AUTOS
Provides access to:
•
Autostroke commissioning routine.
Note: SET and RUN functions can only be accessed after a successful
AUTOSTROKE routine has been completed.
•
Selection of percentage travel display % (TRAVL).
SET
Provides access to valve set up functions as follows:
•
Valve type (VALVE).
•
Control action (CTRLA).
•
Deadband (dBAND)
•
Split range (SPLIT).
RUN
Provides access to:
•
Commencing automatic operation.
•
Displaying percentage valve travel (%).
•
Visualisation of input mA input signal (mA).
•
Return to SP400 menu (RETRN).
