IM-P343-37 CTLS Issue 4
9
SP400 Electropneumatic Smart Positioner
3.4 Programmable functions
Autostroke Automatic commissioning routine
Valve type 2-port or 3-port
% travel Selectable 0 - 100% or 100% - 0% depending on valve/actuator configuration
Control action Direct or reverse action (4 - 20 or 20 - 4 mA)
Split range
OFF range 4 - 20 mA
LOW range 4 - 13 mA
HIGH range 11 - 20 mA
Deadband
0.5%
1.5%
3.0%
5.0%
Reset Resets all programmed values to default settings
Input signal Visualisation of input mA signal
