Tech-X Flex™ Base Unit User Guide Issue 1
5: IP and Video Testing 5-5
Intro
Wi-Fi
10/100
System
IP/Video
Specs
Figure 5-2 Successful Ping results
5.4 Traceroute
This test is the standard ICMP traceroute function that sends three traceroute requests to a destination
address and reports every router “hop” along the path, up to 30 hops. The results provides a topological
view of the route that the packets used to reach the destination.
The request is sent via the active interface and requires that routable IP information is assigned to that
interface. For more information, see IP Network Setup on page 5-1.
5.4.1 Setup - Traceroute test
Table 5-4 Traceroute - Setup parameters
Parameters Description
Destination IP
Address
Target address for the traceroute request, either a dotted IP address or a URL if
a DNS is available. For example:
208.22.58.142
www.google.com
