Section-2 Safety and Information Labels
1. Thoroughly clean and dry the area where the label is
to be installed.
2. Determine the exact label position before removing the
backing paper. Center the label so no edge will extend
beyond the flat surface to which it is being affixed.
3. Remove the smaller section of the backing paper.
4. While holding the exposed adhesive away from the
surface, rest the covered portion of the label on the
surface. Align the label in the chosen position.
5. Starting at the center, press the sticky portion of the
label to the machine surface. Press out any trapped air
bubbles as the label is applied.
6. Fold the label back to expose the remaining backing
paper. Peel the backing paper from the adhesive while
carefully pressing the label into position.
7. Small air bubbles can be deflated by piercing them
with a pin and pressing out the air using the slick side
of the backing paper.
2.7. Installing Replacement Labels
2.6. Label Identification and Part Number
Item # Qty* Part # Description
1 1 300091 LABEL,DANGER,ROTATING,DRIVELINES,(VERT)
2 1 300092 LABEL,DANGER,ROTATING,DRIVELINES,(HORZ)
3 11 300087 LABEL,WARNING,EXPOSED,DRIVE,CAN CAUSE
4 3 300088 LABEL,WARNING,MOVING,MACHINE,CAN,CAUSE
5 2 300090 LABEL,WARNING,FLYING,OBJECTS,CAN,CAUSE
6 1 300097 LABEL,WARNING,HIGH,PRESSURE,OIL,CAN
7 2 300096 LABEL,WARNING,HEAVY,TONGUE,WEIGHT,CAN
8 4 300086 LABEL,CAUTION,MOVING,DRIVES,CAN CAUSE
9 3 300089 LABEL,CAUTION,LOW,SPEED,TIRE,CAN,CAUSE
10 2 300093 LABEL,CAUTION,SLIPPERY,SURFACES,CAN
11 1 300922 STICKER, DRAWBAR HOSES 6640/6630
12 2 300466 NOTICE:MODIFICATION MAY VOID WARRANTY
13 2 300601 STICKER, ELEC/HYD MODS VOID WARRANTY
14 2 300213 DECAL,LIFT POINT
15 5 300400 TAPE,RED,REFLECTIVE x 9"
16 10 300401 TAPE,YELLOW,REFLECTIVE x 9"
17 5 300402 TAPE,ORANGE,REFLECTIVE x 9"
18 1 300106 SIGN,SLOW,MOVING,VEHICLE (ASSEMBLED KIT)
19 1 300055 SERIAL,NUMBER,PLATE 2"x3" ALUM W/HOLES
20 1 300250 LABEL,MAINTENANCE STICKER,SPANISH
21 1 300251 LABEL,MAINTENANCE STICKER,ENGLISH
22 2 300166 STICKER,SPUDNIK,6.1" X 29.49" LG WHITE
23 5 300168 STICKER,SPUDNIK,3.82"x18.49" SMALL WHITE
24 1 301564 STICKER,MDL 6740 WHITE,LRG,ARIAL 2019
25 1 301567 STICKER,MDL 6740 WHITE,LRG,ARIAL 2019
* Quantity of each label may vary depending on options installed.
1. Use table 2.6 in conjunction with images 1 through 19
to identify the location for each of the labels used on
the 6740 harvester.
2.8. Label Locations
