Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
116
Section-3 Parts Manual
FB1693 - CCI DISPLAY AND MOUNTS
Item # Qty Part # Description
1 1 982825 CAP, TUBE, RIBBED, 1.25" ODX 1" ID
2 1 177487 MOUNT ARM, UPPER, S4 CONTROLS
3 1 177488 MOUNT ARM, LOWER, S4 CONTROLS
4 3 981250 KNOB,CLAMPING,W/STUD 3/8"-16x1" 5993K41
5 1 177489 MOUNT BRACKET, CCI DISPLAY,S4
6 1 19010428 CONTROL MOUNT,HORIZ SLIDE
7 1 EA0277 TERMINAL,KIT,CC1-200,DISPLAY
