Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
107
Section-3 Parts Manual
134445 - ASSY,FOLD OVER BOOM,42",6740-19
Item # Qty Part # Description
1 1 179399 SENSOR MNT,SLW DWN,FLD OVR BM,6621-17
2 1 403165 SENSOR,PROXIMITY 8MM,M18,M12-4P
3 1 502212 COLLAR,SHAFT,SET,SCREW,3/8"
4 1 19017566 MOUNT, SPRINGS, M-SEP, HEAVY WEIGHT, 994
5 1 17010934 HOSE SUPPORT,FOLD OVER BOOM,6740-19
6 2 502829 COLLAR,SHAFT,CLAMP ON,1"
7 1 178351 HOPPER MOUNT,REAR,BOOM,5740-2016
8 1 982305 GROMMET,EPDM,3"ID,1/4" WOG,4"OD
9 2 352245 RLR,BC,PU,5/8X4X1,SC
10 2 502716 COLLAR,SHAFT,CLAMP,1-1/4"
11 1 17010893 VALVE MOUNT,BOOM,6 STTN,6740-19
12 1 17010916 SHIELD,VALVE,FOLD OVER BOOM,6740-19
13 4 111012 BUSHING,.66"ID BORE x 3.25"LG x 1.24"OD
14 2 501900 COLLAR,SHAFT,SET,SCREW,5/8"
15 2 502798 BOLT,HEX,HD,1"-8UNC x 3-1/2",SHRT HD GR8
16 2 171807 SPACER,CYL,SHKR,1/2"x1.13"IDx2.25"OD
17 34 351309 STANDOFF,RLR,BC,5/8"x1-1/4"
18 8 351311 RLR,BC,PU,5/8X3.5X2.375X5FL,PC
19 30 351314 RLR,BC,PU,5/8X4X1,PC
20 8 352252 RLR,BC,PU,5/8X3.5X1X5FL,SC
21 2 351316 RLR,BC,PU,5/8X3.5X2.375,PC
22 2 192768 WELD,PIVOT PLT FOBOOM 6400-2005
23 2 192099 PIN,PIVOT BOOM HARV-2004
24 1 196675 FRAME,PICKING TABLE,42",6640-2011
25 2 191879 PIN,PIVOT P.T. EXT
26 1 197046 PIVOT LINK,FOLD OVER BOOM,42IN,66X0-2012
27 2 191999 LEVER,BOOM FOLD OVER 6400-2004
28 1 197044 BOOM,INNER,42IN FOLD OVER,66X0-2012
29 2 603767 CYL,3.00"x36",WELDED,46.25",1.5",-8
30 2 603756 CYL,2.00"x10",WELDED,20.25",1.125",-8
na 2 172896 WASHER,4-21/64" DIA 3/16
na 2 353041 RLR,BC,PU,5/8X5X1,SC
To Next Page
