Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
69
Section-3 Parts Manual
FB5034 - SECONDARY 1 ROCKER SHAKERS,6740S-19
Item # Qty Part # Description
1 1 175182 ROCKER SHAKER MOTOR MOUNT 66X0-2011
2 2 231117 HOUSING,BRNG,4HOLE,85MM,FLANGETTE PLATED
3 1 231335 HOUSING,BRNG,85MM,STEEL,TEARDROP,BHTD850
4 3 231114 BRNG,INSERT,1-3/4",ECC,LOCK/SPHR
5 1 604763 MTR,HYD,8CUIN,1" KEY,SAE-A,TE SERIES
6 12 351313 RLR,BC,PU,5/8X5X1,PC
7 4 17010906 PLATE,RLLRS,NO SEC SHKR,FRONT,6740-19
8 4 501900 COLLAR,SHAFT,SET,SCREW,5/8"
9 12 351310 STANDOFF,RLR,BC,5/8"x3-5/8"
10 1 502689 BOLT,HEX,HD,3/4"-16UNF x 4" GR8
11 2 502690 NUT,HEX,3/4"-16UNF GR 8
12 2 502421 WASHER,FLAT,3/4",ZINC PLT,SAE
13 1 133343 ASSY,SHAKER SHAFT,STD SECONDARY,6640-11
14 1 132412 ROCKER,SHAKER ARM ASSY,1"BORE,6140/HARV
NA 1 HA0841 ONE SECONDARY ROCKER SHAKERS,6740
NA 1 HK0868 HOSE KIT,1 SECONDARY ROCKER SHAKER,6740
