Spudnik 6740 - Fb5043 - Vine Chain,Sec Sec,High Routing,6740-19

Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
73
Section-3 Parts Manual
FB5043 - VINE CHAIN,SEC SEC,HIGH ROUTING,6740-19
Item # Qty Part # Description
1 1 881173 SPRCKT,H80BS16x2" BORE 1/2" KEYWAY
2 1 982254 BUMPER,RUBBER,3/4"DIAx1/2" HIGH 10-24
3 1 262277 RUBBER PLATE,2"x2" VINE SHIELD,6640-2012
4 1 175449 STOP,SHIELD,VINE CHAIN,66X0-2012
5 1 231120 BRNG,4BOLT,FLNG,TCJ 2",ECC LOCK
6 2 231122 BRNG,PB,1-3/4",ECC LOCK "R"SEAL WIDE
7 1 17010978 SPACE,SHIELD STOP,3/16",6740-19
8 2 173189 SCRAPPER, DRUM, DEV 6400-2004
9 1 881191 SPRCKT,H80BS23x1-3/4" BORE 3/8" KEYWAY
10 1 196724 SUPPORT,SHIELD PRIMARY DRIVE,66X0-2011
11 1 351275 CHN,RLR,80 PITCH 7.25'
12 1 050236 SHFT,7K,2"x156.50" WIDE SEP SCNDRY
13 2 231115 BRNG,INSERT,2",ECC,LOCK/SPHR
14 2 352245 RLR,BC,PU,5/8X4X1,SC
15 2 231118 HOUSING,BRNG,4HOLE,100MM,FLANGETTE PLATD
16 4 17010865 ANTI WRAP VINE CHAIN, 67XX-19
17 2 501900 COLLAR,SHAFT,SET,SCREW,5/8"
18 1 351275 CHN,RLR,80 PITCH 17.75'
19 1 881336 SPRCKT,H80BS26 x 1-3/4" BORE 3/8" KEYWAY
20 3 881140 IDLER,80,PITCH,5/8" BORE 12 TOOTH #704
21 4 981646 CLEVIS,FORK,THREADED ENDS,M8
22 1 981664 HANDLE,SHIELD,6140 NA4ZN
23 2 881196 IDLER,CHAIN,60/80PITCH ASSY 2868BD2X
24 8 351306 RLR,BC,PU,5/8X3.5X2.375X5FL,SC
25 30 171313 SPACER,NOSE,ROLLER,1/4"x5"ODx11/16"ID
26 22 351311 RLR,BC,PU,5/8X3.5X2.375X5FL,PC
27 6 351309 STANDOFF,RLR,BC,5/8"x1-1/4"
28 4 354615 RLR,BC,PU,5/8X3X1,PC
29 30 019.00435 WINDING PROTECTION 5.250"
30 1 196700 OVERRIDE ROLLER,STD CNTR,6640-2011
31 1 881184 SLIPCLUTCH,ASSY,80P48Tx2" BORE 8 BOLT
32 1 982000 SPRING,GAS,7.87STROKE,75# FORCE,M8THREAD
33 1 191071 BOLT,IDLER,5/8"x3" W/TAB
34 1 19017538 SHIELD, RH, REAR, 6740-19
35 1 981950 SPRING,GAS,7.87STROKE,200# FORCE,M8THRED
36 1 301567 STICKER,SRIPE, RH REAR, STD SEC, 6740-19
