Part #: 290360
Revision: 5/24/2022
75
Section-3 Parts Manual
FB5068 - STRIPPER,STD SEC,DBL ROW,HYD ADJ,6740-19
Item # Qty Part # Description
1 1 881136 SPRCKT,H80BS20x1-3/4" BORE
2 2 174649 PLATE, SPACER 3/8IN,STRIPPER KIT,6400-10
3 2 231321 BRNG,2BOLT,FLNG,1-3/4".ECC LOCK
4 2 501220 HAIRPIN,COTTER,3/16"x3-3/4" #21-08
5 2 090265 TUBE
6 1 175398 BACKING PLATE, TANK, 66X0-2012
7 2 601589 STOP,CYLNDR,STROKE,1-1/2",LONG CLIP ON
8 4 175673 SPACER, UNDERDRUM,STRIPPER-KIT,6160-2012
9 6 174185 PLATE,MOUNT,TURNBUCKLE,6160-2007
10 1 050009 PIN, DISC COULTER HYD CYL MOUNT
11 4 179488 SPACER, STRIPPER CONNECT PLATE, 6640-17
12 2 502698 BOLT,EYE,5/8"x5" THREADED 4-1/4"
13 1 501900 COLLAR,SHAFT,SET,SCREW,5/8"
14 1 17010567 LINK, LOWER, STRIPPER KIT, 6640-2018
15 1 17010566 LINK, UPPER, STRIPPER KIT, 6640-2018
16 12 351311 RLR,BC,PU,5/8X3.5X2.375X5FL,PC
17 12 019.00435 WINDING PROTECTION 5.250"
18 12 171313 SPACER,NOSE,ROLLER,1/4"x5"ODx11/16"ID
19 16 176210 SPACER, STRIPPER KIT, 66x0-2013
20 4 173038 MOUNT, STRIPPER KIT HARV/6140-2004
21 60 099.00012 WASHER 13
22 60 023.12251 ANGULAR BRKT STRAP
23 16 090571 TUBE,MEC,.750"ODx.120"WALL DOM
24 16 097.00021 SPRING, PULL
25 16 181501 NUBBIN,1"ODx1-1/4" LONG D 5/8"
26 16 031.00634 EYELET BOLT,10X145
27 2 192190 STRIPPER KIT MAIN SUPPORT
28 1 195642 UNDERDRUM,STRIPPER KIT,STD SEC,4ROW-2010
29 2 193384 SCRAPPER,STRIPPER,KIT 6440-2005
30 1 197065 CYLINDER MOUNT,HYD STRIPPER,66X0-2012
31 4 192185 STRIPPER LINK,LH SHORT
32 1 603755 CYL,2.00"x8",WELDED,20.25",1.125",-8
33 2 192186 STRIPPER LINK,RH LONG
34 44 076.04142 BACK-HOLDING PLATE (SPRING WITH PADDLE)
35 8 982431 PADDLE,STRIPPER KIT,OFFSET LH
36 2 192187 HOLDER
37 6 192184 HOLDER
38 2 192188 STRIPPER LINK,LH LONG
NA 8 982430 PADDLE,STRIPPER KIT,OFFSET RH
NA 2 171807 SPACER,CYL,SHKR,1/2"x1.13"IDx2.25"OD
NA 1 HA0833 STRIPPER KIT,6740
NA 1 HK0861 HOSE KIT,STRIPPER KIT ADJUST,6740
FA8991 - DEVINER NO CHAIN 66XXX-2012
Item # Qty Part # Description
NA na na na
(NO ASSEMBLY DRAWING AVAILABLE)
