Spudnik 6740 - Page 6

Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
iv
Table Of Contents
Cleaning Table
FB6182 - SMPL M-SEP,5 STL RLR,FIX,P CTRL,6740S-22 .................................................... 90-94
133336 - ASSY,SPRDR RLLR,LG,46STRS,SE SEP,66X0-11 ................................................ 96
132474 - STARROLLER,41-1/2",12 FNGR,6400-2004 ............................................................ 97
132473 - STARROLLER,20-1/2 12FNGR 6400-2004 .............................................................. 98
Boom
FB5063 - BOOM,FOLD OVER,42",SWING,6740S-19 ............................................................. 100
134447 - MOUNT PARTS,SWING BOOM,42",6740-19 ........................................................... 102
134457 - ASSY,BOOM HOPPER,42",STD WIDTH,67X0-19 ................................................... 104
134445 - ASSY,FOLD OVER BOOM,42",6740-19 ................................................................... 106
FB3235 - FLD OVR OTR BM,42",EXT LNGTH,6640-17 .......................................................... 108
FB2102 - FOLD OVER BOOM MOTOR WITH BRAKE,66X0-16 ............................................. 109
FA8026 - NO PICKING TABLE/BOOM CHAIN HARV ............................................................. 109
FA6330 - SPRCKT,STEEL 45MMx1-3/8B 2EA,INTNL DRV .................................................... 109
Axle
FB5019 - AXLE,HYD PIVOT, 2 TIRE, 6740S-19 ..................................................................... 110
134442 - ASSY, 2 WHEEL PIVOT AXLE, 6740S-19 ............................................................... 112
FA7284 - HIGH FLOAT 750/45x22.5 TIRES HARV-09 ............................................................ 114
Controls
FB1693 - CCI DISPLAY AND MOUNTS .................................................................................. 116
EA0277 - TERMINAL,KIT,CC1-200,DISPLAY ......................................................................... 117
EA0979 - 6740, STD S4 ELEC ASMB, 2019 ........................................................................... 118
FB1701 - CONTROL MOUNT BASE, JD TRACTOR ............................................................... 120
FB5100 - SENSOR PACKAGE,SEC DL END DRV,6740S-19 ................................................. 121
Schematics
4.1 Electrical ................................................................................................................................... 122-132
4.2 Hydraulic .................................................................................................................................. 134-175
5. Miscellaneous Specifications & Reference
5.1 Fastener Torque Guidelines ..................................................................................................... 176
5.1.1 Fastener Torque Chart (SAE) ........................................................................................ 176
5.1.2 Fastener Torque Chart (Metric) ..................................................................................... 176
5.1.3 Fastener Grade/Class Marking ...................................................................................... 176
5.2 Shear Pin Guidelines ..................................................................................................... 177
5.3 Hydraulic Fittings Guidelines .................................................................................................... 177
5.3.1 Flare Connection Torque Methods ................................................................................ 177
5.3.2. Hydraulic Flare Type (JIC) Fitting Torque Chart ............................................................ 177
5.4 Belted Chain Repair ...................................................................................................... 178-181
5.5 Lubricant Specifications ........................................................................................................... 181
5.5.1 Fluids and Lubricants .................................................................................................... 181
5.5.2 Storing Lubricants .......................................................................................................... 181
