Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
98
Section-3 Parts Manual
132473 - STARROLLER,32-1/2",12 FNGR,6400-2004
Item # Qty Part # Description
1 1 981229 ROLL,RUBBER,SPACER,1/2" x 1-1/4" SQ BORE
2 1 501950 COLLAR,SHAFT,SET,SCREW,1-1/4"
3 1 501908 WASHER,FLAT,3/4" USS ZINC PLT (9/LB)
4 1 502319 SCREW,FLAT,SCKT,HD,1/2"-13 x 1"
5 1 821384 SHFT,SQ,HARV,1-1/4"SQ x 32" FNGR STB
6 17 981294 ROLL,RUBBER,FINGER,12POINT,1-1/4"BORE"A"
7 1 981311 ROLL,RUBBER,12 POINT,1-1/4"B RECESSED RH
