Par ts Ma nual 6740 Har vest er
Part #: 290360
Revision: 5/24/2022
41
Section-3 Parts Manual
FB5014r5 - COULTERS,SNGL PVT,SNGL BLD,67XX-19
Item # Qty Part # Description
1 12 175298 SPACER INTRMDTE COULTERS HARV/WIND-2011
2 8 502337 BOLT,HEX,HD,5/8"-11UNC x 7" GR 8
3 2 951462 SEAL,WHEEL,BEARING,2.625"x3.250"x.375"
4 2 310035 HUB,COULTER,4"ODx2.9"IDx3"L,6HOLE,5.25BC
5 2 090273 SPACER TUBE 1.25" ID x 3.25" LONG
6 2 050752 SHAFT, COULTER, TELESCOPING
7 4 17010853 ARM,COULTER LIFT,SNGL PVT,67XX-19
8 4 571079 CAP,DUST,WHL,DRV,GRBX FOR #710 (3.255")
9 4 171806 SPACER,CYL,SHKR,1/4"x1.13"IDx2.25"ID
10 4 502826 BRNG LOCKNUT,1.767"-18
11 8 951172 RACE,TAPERED,2",BEARING,WHEEL CUP
12 4 501217 BOLT,HEX,HD,1"-8UNC x 6" GR 5
13 2 981267 SPRING,26"x2",COMPRESSION .437"DIA WIRE
14 2 321580 TRUNNION,COULTER,SPRING,STOP 2"x2"x4.50"
15 2 951171 SEAL,WHEEL,BEARING,2.625"x3.500"x.375"
16 8 231125 BRNG,WHEEL,2",TAPERED ROLLER(WHEEL CONE)
17 9 502302 SCREW,CAP,SCKT,HD,1/2"-20NF x 1-1/4"
18 4 016770 STAR,LOCK,COULTER NUT
19 2 198724 COULTER ARM,REAR,TELE CLTR,6640-13
20 2 210032 PLATE,COULTER,REINFORCEMENT,1/4" x 6HOLE
21 2 198723 COULTER ARM,FRONT,TELE CLTR,6640-13
22 2 198731 SPRING ROD,COULTER 5640-2013
23 2 603755 CYL,2.00"x8",WELDED,20.25",1.125",-8
24 2 19017457 COULTER UPRIGHT,67XX-19
na 1 HA0827 COULTERS,6740
na 1 HK0855 HOSE KIT,COULTERS,6740
