SPX FLOW W63 - Page 49

Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 49
W61/W81 Shutoff Valve
Item # 1" & 1-1/2" 2" 2-1/2" 3" 4" 6" Notes
Control Top
1 Actuator
* 2 Bearing 106047+
3 Adapter, W60 (Std.) 102407+ 102408+ 102409+ 102410+ 113822+
3a W60 109294+ 109295+
W80 116926+ 116927+
3b Adapter, W80 106292+ 106293+ 106294+ 106295+ 114306+ 2
3c Adapter, W81A 117786+ 117787+ 117788+ 117789+ POA 3
3d
117880+ 117881+ 117882+ 117883+ POA 1
* 4 O-ring EPDM E70214
FKM V70214
* 4a EPDM POA
FKM POA
5 Clamp Standard 119-33 119-34 119-51 119-87 113827+
High Pressure 119-272 119-273 4
* 6 EPDM E70228 E70232 E70236 E70244 E70258
FKM V70228 V70232 V70236 V70244 V70258
7
Tef-Flow
TM
102413+ 102414+ 102415+ 102416+ N/A
Tri Ring
108132+ 107045+ 108134+ 108135+ 113823+
Metal
106388+ 106389+ 106390+ 106391+ P.O.A
* 8 Seat Ring
Tef-Flow
TM
20-241 20-242 20-243 20-244 POA
Tef-Flow
TM
P
115348+ 115349+ 115350+ 115351+ POA
Tri Ring, EPDM 107695+ 107048+ 102488+ 107698+ 102738+
Tri Ring, FKM 107986+ 107982+ 107974+ 107989+ 108020+
10
PL5027-CH1
108131+
106387+
Adapter, Wiping Stem
Seal
O-ring,
Body
High Pressure Backup
Ring
POA
Stem (less
seat ring)
20-240
115347+
107692+
107983+
BURT210
1
115626+
119-30
119-271 POA
E70223
5
109293+ POA
V70223
102412+
106291+
117785+
117879+
E70210
V70210
116925+ POA
Wiping
Stem Seal
116183+
Part Description
Contact Factory
See actuator parts list
102757+
102406+
Adapter,
High Press.
Notes:
* Recommended Spare Parts
1. Wiping Stem Seal Adapter and Wiping Stem Seal
options available for W60 Series valves only.
2. W80 Adapter allows for liquid or steam flush of stem o-ring only.
3. W81A Adapter allows for liquid or steam flush of stem o
-ring and body o-ring. Only available on one-piece body
configurations.
4. High Pressure Body Clamp only required for valves equipped with High Pressure Adapter (item 3a).
5. W81A Adapter requires two body o-rings.
POA: Contact Factory
