SPX FLOW W63 - Hand Lock Manual Handle

Parts Lists Waukesha Cherry-Burrell Brand W60/W80 Valves
Page 82 95-03022 08/2018
Hand Lock Manual Handle
Item # Part Description Part No.
Note
Actuator Assembly 105167+
1 Hex Nut 36-54
1
2 Plane Washer 43-31
3 Retaining Ring 2104600+
4 Nut-Adjusting 2098700+
5 Locknut with Handle 36-50
6 Plain Washer 43-55
7 Stem - Manual Actuator 105168+
8 Adjusting Screw Assembly 105170+
PL5027-CH39
Notes
1. The hex nut is only used for shipping. The hex nut is not used when the actuator is installed on a valve.
