SPX FLOW W63 - Micrometer Handle

Parts Lists Waukesha Cherry-Burrell Brand W60/W80 Valves
Page 84 95-03022 08/2018
Micrometer Handle
Item # Part Description Part No.
Actuator Assembly 112884+
1 Yoke 112881+
2 Handle 112882+
3 Stem 112883+
4 Bearing 102757+
5 Retaining Ring 113163+
6 Clip 65-1
7 O-Ring, PTFE Coated 9-40
PL5027-CH41
Notes
1. When the micrometer handle assembly is ordered as a loose component, a vernier scale is not acid-etched on the
handle and body.
