SPX FLOW W63 - Maintenance Free Actuator Cap; Maintenance Free Actuator Yoke

Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 81
Maintenance Free Actuator Cap
3
2
1
4
VA100-771
Item # Part Description
A Size
(74 mm)
B Size
(110 mm)
C Size
(165 mm)
- Cap Assembly Complete * 18MB816568 18MB816503 18MB816503
1 Cover Plate 18HP816649 18HP816333 18HP816333
2 Cap 589P800276 589P800276 589P800276
3 Jam Nut H79298 H79298 H79298
4 Screw 521SR238FB 521SR238FB 521SR238FB
PL5027-CH187
Notes
* Cap Assembly Complete includes (1) Cover
Plate, (1) Jam Nut & (4) Screws
Maintenance Free Actuator Yoke
Part Description Qty Part No.
Yoke, Maintenance Free Actuator 1 131625+
Bolt (not shown) 4 M521SR203FB
PL5027-CH204
