Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 51
W61Y Shutoff Valve
Item # 2-1/2" 3" 4"
Notes
1 Actuator
* 2 Bearing
3 Adapter, W60 (Std.) 119617+ 119618+ 119619+
3d Adapter, Wiping Stem Seal 122002+ 122003+ 122004+
* 4 O-ring EPDM
FKM
* 4a Wiping Stem Seal EPDM
FKM
5 Clamp Standard 119-87 119-87 113827+
* 6 O-ring, Body EPDM
E70241 E70244 E70257
FKM
V70241 V70244 V70257
Stem (for use with TFP seat ring) 118479+ 118480+ 118481+
Stem (for use with O-Ring seat) 127012+ 127011+ 127013+
Seat Ring
Tef-Flow
TM
P
118476+ 118477+ 118478+
O-Rin
g
EPDM
E80336 E80344 E80356
FKM
V80336 V80344 V80356
PL5027-CH2
1
116185+
7
*8
Part Description
See actuator parts list
106047+
E70214
V70214
116184+
Notes:
* Recommended Spare Parts
1. Tef-Flow™ P seat is not recommended for manual actuation configu
ration; Standard O-ring seats should be used with
manual actuation.
