SPX FLOW W63 - Page 53

Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 53
W62/W82 Divert Valve
Item # 1" 1-1/2" 2" 2-1/2" 3" 4" Notes
Control Top
1 Actuator
* 2 Bearing
3 Adapter, W60 (Std.) 102407+ 102408+ 102409+ 102410+
3a W60 109294+ 109295+
W80 116926+ 116927+
3b Adapter, W80 106292+ 106293+ 106294+ 106295+ 2
3d Adapter, Wiping Stem Seal 117880+ 117881+ 117882+ 117883+ 1
* 4 O-ring EPDM
FKM
* 4a EPDM 1
FKM
5 Clamp Standard 119-33 119-34 119-51 119-87
High Pressure 119-272 119-273 3
* 6 O-ring, Body EPDM E70228 E70232 E70236 E70244
FKM V70228 V70232 V70236 V70244
7
Tef-Flow
TM
102423+ 102424+ 102425+ 102426+ 102427+ 102428+
Tef-Flow
TM
Long Stroke
N/A N/A N/A 139084+ 110935+ 110937+
Tri Ring 108154+ 108155+ 108156+ 108157+ 108158+ 108159+
Tri Ring, Long Stroke
N/A N/A N/A 110983+ 110984+ 110985+
Metal
106392+ 106393+ 106394+ 106395+ 106396+ 106397+
Metal, Long Stroke
N/A N/A N/A 110998+ 110999+ 111000+
* 8 Seat Ring
Tef-Flow
TM
20-241 20-242 20-243 20-244
Tef-Flow
TM
P
115348+ 115349+ 115350+ 115351+
Tri Ring, EPDM 107695+ 107048+ 102488+ 107698+
Tri Ring, FKM 107986+ 107982+ 107974+ 107989+
10 High Pressure Backup Ring
PL5027-CH3
Wiping Stem
Seal
Stem (less seat ring)
N/A119-271
116925+
106291+
Adapter, High
Pressure
117879+
119-30
BURT210 N/A
N/A
N/A
E70210
Contact Factory
See actuator parts list
V70223
20-240
115347+
E70223
107983+
Part Description
102757+
102406+
109293+
107692+
V70210
116183+
115626+
* Recommended Spare Parts
1. Wiping Stem Seal Adapter and Wiping Stem Seal options available for W60 Series valves only.
2. W80 Adapter allows for liquid or steam flush of stem o-ring only.
3. High Pressure Body Clamp only required for valves eq
uipped with High Pressure Adapter (item 3a).
