W65/W85 Non-Slam Divert Valve
Item # 1" 1-1/2" 2" 2-1/2" 3" 4" Notes
Control Top
1 Actuator
* 2 Bearing
3 Adapter, Upper - W60 (Std.) 102407+ 102408+ 102409+ 102410+
3a W60 109294+ 109295+
W80 116926+ 116927+
3b Adapter, Upper - W80 106292+ 106293+ 106294+ 106295+ 2
3d 117880+ 117881+ 117882+ 117883+ 1
* 4 O-ring EPDM
FKM
* 4a EPDM
FKM
5 Clamp Standard 119-33 119-34 119-51 119-87
High Pressure 119-272 119-273 3
* 6 O-ring, Body EPDM E70228 E70232 E70236 E70244
FKM V70228 V70232 V70236 V70244
7a
Tef-Flow
TM
121963+ 121963+ 121964+ 121965+ 121966+ 121967+
Tri Ring
POA 128178+ 127799+ 124016+ 128347+ 128358+
Metal POA POA 131663+ 129233+ 130984+ POA
7b
Tef-Flow
TM
121974+ 121975+ 121976+ 121977+ 121978+ 121979+
Tef-Flow
TM
Long Stroke
N/A N/A N/A 125952+ 125954+ 125958+
Tri Ring
POA 128179+ 127800+ 124018+ 128349+ 128360+
Tri Ring, Long Stroke N/A N/A N/A POA POA POA
Metal
106286+ 106286+ 131712+ 129232+ 130983+ POA
Metal, Long Stroke N/A N/A N/A POA POA POA
* 8 Seat Ring
Tef-Flow
TM
20-241 20-242 20-243 20-244
Tef-Flow
TM
P
115348+ 115349+ 115350+ 115351+
Tri Ring, EPDM 107695+ 107048+ 102488+ 107698+
Tri Ring, FKM 107986+ 107982+ 107974+ 107989+
* 9 EPDM E70215 E70215 E70215 E70215
FKM V70215 V70215 V70215 V70215
10 High Pressure Backup Ring
11 Adapter, Lower - W60 (Std.) 106240+ 106241+ 106242+ 106243+
11a W60 103634+ 103635+
W80 116932+ 116933+
11b Adapter, Lower - W80 106297+ 106298+ 106299+ 106300+ 2
11d
117981+ 117982+ 117983+ 117984+ 1
PL5027-CH8
Wiping Stem
Seal
1
Adapter, Lower -
High Pressure
3
Adapter, Upper -
High Pressure
Adapter, Lower-Wiping Stem
Seal
106291+
117879+
E70210
V70210
O-ring, Lower
Stem
Part Description
102757+
102406+
109293+
116925+
Contact Factory
See actuator parts list
N/A
N/A
119-30
119-271
E70223
V70223
20-240
115347+
106328+
117979+
N/A
116183+
115626+
107692+
107983+
N/A
BURT210 N/A
Stem, Upper
(less seat ring)
Stem, Lower (less seat ring):
A
dapter, Upper-Wiping Stem
Seal
N/A
103632+
116930+
E70206
V70206
106329+
Notes:
* Recommended Spare Parts
1. Wiping Stem Seal Adapter and Wiping Stem Seal option
s are available for the W60 Series valves only.
2. W80 Adapter allows for liquid or steam flush of the stem o-ring only.
3. High Pressure Body Clamp is only required for valves equipped with High Pressure Adapters (items 3a and 11a).
