Item #
6" Diameter Notes
1 Indicator Stem - Visual 110296+
1a Indicator Stem - WCB 2-piece Control Top 110800+
1b Indicator Stem - Bürkert 8681 Control Top 134716+ 2
1c Indicator Stem - CU4 control Top N/A 2
1d Indicator Stem - Set and forget 119679+ 3
3 Stem, Lower 2-1/2" valve 110299+
3" valve 110299+
4" valve 110299+
4 Cylinder 106007+
* 5 Bearing, Cylinder 102757+
* 6 O-ring Nitrile N70210
* 7 O-ring, Cylinder Nitrile N70255
* 8 O-ring, Piston Nitrile N70433
9 Cap Screw, 1/4-20 x .375" lg. 30-68
10 Piston Assembly 118239+
* 11 O-ring Nitrile N70214
12 Yoke 110298+
* 14 Bearing, Piston 102052+
* 15 Bearing, Yoke 106047+
16 Spacer 2-1/2" valve
110868+
3" or 80 valve
110871+
4" or 100 valve
N/A
Actuator Seal Kit (contains recomm. spares)
129867+
Valve 6" Diameter Notes
ir-to-Air 2-1/2 ACT00258 2
3 ACT00259 2
4 ACT00260 2
2-1/2 ACT00261 3
3 ACT00262 3
4 ACT00263 3
PL5027-CH27
Visual Indicator Stem
Control Top Indicator Stem
Part Description
Complete Actuator Assemblies (see note 4)
6" Air-to-Air Long Stroke Actuator
Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 73
Notes
* Recommended Spare Parts
1. Long stroke actuators are not available for the W9
0 series diaphragm stem valves.
2. Stem only - does not include target
3. Stem for use with WCB 2-piece control top
4. Assemblies are different for each valve size.
